Counter Timeline

The Counter Timeline shows the values of all counters that a given trace file provides. The Intel® Trace Collector records user-defined counters or counters provided by the operating system. See the Intel® Trace Collector User and Reference Guide to learn more about tracing counters.

Intel® Trace Analyzer

Element: Description:
Line segments Connect sample points for counters with the Curve attribute
Markers Show sample points with the Valid AT point attribute
Short unconnected horizontal line segments Show counter samples with other scopes
Status bar at the bottom of the panel If the mouse pointer is near a sample point, then its exact position in time is shown.

Note

There are no markers anymore because the values shown represent samples that were merged over time. To force that effect the View was made very narrow.
